Wet Milling System

Brewery banner

Wet Milling System

Wet Milling System
Wet Milling System

Wet Milling System Efficient brewing starts with improved milling. Our system combines the benefits of conventional wet and dry milling, which ensures almost perfect husk conservation and optimal grinding of the endosperm. The end result provides numerous advantages for your brewing process and your final product beer.

VIDEO

FEATURES

  • Hygienic design ensures simple and efficient cleaning
  • Eccentric screw pump for mashing-in: malt to water ratios of up to 1:2 (without rinsing) can be reliably handled
  • Level control in mash hopper for low oxygen uptake
  • Optimized spray geometry to reduce mash flotation
  • Quality automation system: feed roller speed control based on grist throughput rates provides adjusted steeping time for “harder” malt batches
  • Steeping water temperature and flow are individually adjustable
  • Precise and easy adjustment of the crushing roller gap
  • Large rollers for optimal crushing and husk conservation
  • Mash acidification is possible directly in the mill
  • On request, inert gas flushing can be accommodated
  • Less ATEX protection measures required because of the wet grist

PARAMETERS

Power(KW) Rotating speed(RPM) Capacity(kg/h)
7.5/11 0~6000 50~500
15/18.5 0~4500 200~1000
30/37/45 0~4000 500~5000
7.5/11 0~6000 50~500
15/18.5 0~4500 200~1000
30/37/45 0~4000 500~5000
75/90 0~3000 5000~10000
